Steelcraft Automotive 71330 BULL BAR - Manual

Page 1 of 4 5/5/08 (AM) Rev A
PARTS LIST:
1 Bull Bar 4 10mm Nylock Nuts
1 Driver/Left Mounting Bracket 4
10mm ID x 30mm OD x 2.5mm Flat
Washers
1 Passenger/Right Mounting Bracket 2 12-1.75mm x 50mm Hex Head Bolts
1 Driver/Left Bull Bar Bracket 4 12-1.75mm x 30mm Hex Head Bolts
1 Passenger/Right Bull Bar Bracket 4 12mm Nylock Nuts
2 Top Support Brackets 2 12mm Lock Washers
1 10-1.50mm Driver Side U-Bolt 10 12mm ID x 37mm OD x 3mm Flat Washers
1 10-1.50mm Passenger Side U-Bolt 2 8mm Nylock Nut
2 8-1.25mm x 20mm Bolt Plate (58mm x 18mm plate) 2 8mm ID x 24mm OD x 2mm Flat Washers
I NSTALLATION INSTRUCTIONS
BULL BAR
08-ON FORD ESCAPE / 08-ON MAZDA TRIBUTE
PART NUMBER
Passenger Side
Mounting Bracket
Driver Side
Mounting Bracket
Passenger Side
Bull Bar Bracket
Driver Side Bull
Bar Bracket
Top Bracket
(2 pcs)
8mm Bolt Plates
10mm “U” Bolts
