Steelcraft Automotive 74030 BULL BAR User Manual
Installation instructions

PARTS LIST:
1 Bull Bar
2 ½” x 2” Hex Head Bolts
1 Driver/Left Mounting Bracket
2 ½” Lock Washers
1 Passenger/Right Mounting Bracket
2 ½” ID x 1 3/8” OD x 3/32” Flat Washers
PROCEDURE:
1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ
INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
2. NOTE: It may be necessary to remove/relocate front license plate and license plate
bracket. It is not required, but strongly recommended. If local/state law requires a license
plate, license plate relocation kit is available.
3. Remove the six screws from lower part of the bumper that secures the plastic shroud.
Move the plastic shroud to gain access to the tow hooks bolts.
4. Starting on the driver side, locate and remove the two front 10mm factory bolts securing
the tow hook to the frame. Loosely attach driver side Mounting Bracket to frame using the
factory tow hook bolts. Repeat this step for passenger side.
5. Re-install the plastic shroud back to the vehicle using the factory screws removed is step
3.
Page 1 of 3
12/26/07 (AM)
INSTALLATION INSTRUCTIONS
BULL BAR
99.5-04 NISSAN PATHFINDER
PART #
Driver Side
Mounting Bracket
Passenger Side
Mounting Bracket
