Steelcraft Automotive 55040 GRILL GUARD User Manual
Steelcraft Automotive For the car

GRILL GUARD FOR HONDA CRV 02-06
Page1 of 2
PART LIST
No. Name
Qty RemarKs No. Name
Qty RemarKs
○
1
Grille guard
1
○
11
Spring washer 2
6mm
○
2
Connecting plate
2
○
12
Hex nut
2
M6
○
3
Bracket(right and left) 2
○
13
U-bolt
1
M10×80
○
4
Plate
2
○
14
U-bolt
1
M10×66
○
5
Hex bolt
2
M14×50 ○
15
Flat washer
4
10mm
○
6
Flat washer
2
14mm
○
16
Hex nut
4
M10
○
7
Spring washer
2
14mm
○
17
Hex bolt
4
M12×30
○
8
Hex nut
2
M14
○
18
Flat washer
4
12mm
○
9
Hex bolt
2
M6×25
○
19
Spring washer 4
12mm
○
10
Flat washer
2
6mm
○
20
Hex nut
4
M12
INSTALLATION INSTRUCTIONS
STEP 1 Before you start the installation, make sure that you have all the components listed above.
STEP 2 Please protect your product from being scratched during the process of installing the grille
guard.
STEP 3 Find holes for installation .
STEP 4 Now install all brackets, but note:do not tighten the bolts. Once you tighten the bolts you
will not be able to line up the grille guard with the brackets anymore.So first install the
brackets then install the grille guard,now you must tighten the bracket and bolts,finally
follow up with tightening the grille guard bolts.
