Steelcraft Automotive 50280 GRILL GUARD User Manual
Page 3
GRILLE GUARD
06-10 HUMMER H3/ 09-10 H3T
Page 3 of 3
5/07/12 Rev1 (DP)
Fig 4
(Fig 5) Passenger side Top Bracket
Line up mounting
brackets on Grille
Guard with tow hook
mounting area
Front
(Fig 6) Passenger side Top Bracket
8mm x 20mm Button
Head Bolt
(2) 8mm Flat Washers
8mm Acorn Nut
(Fig 7) Passenger side Top Bracket
Front
Use factory hex
bolt to attach Top
Bracket to vehicle
Front
