24
Model Name HVE-9000 HVE-9900
Technical
Role of usage Long range receiver [RX] Short range receiver [RX]
HDMI compliance HDMI 1.3c
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color depth
HDMI over
UTP cable
transmission
(24-bit)
Full HD
[1080p]
40m [130ft] for CAT5e
50m [165ft] for CAT6
15m [50ft] for CAT5e
18m [65ft] for CAT6
HD
[720p/1080i]
50m [165ft] for CAT5e
60m [200ft] for CAT6
25m [80ft] for CAT5e
30m [100ft] for CAT6
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Equalization 8-level digital rotary control None
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body — ±19kV [air-gap discharge] & ±12kV [contact
discharge]
[2] Core chipset — ±8kV
Input 1x RJ-45 1x RJ-45
Output 1x HDMI 1x HDMI
HDMI connector Type A [19-pin female] Type A [19-pin male]
RJ-45 connector WE/SS 8P8C with 2 LED indicators
Rotary control switch 8-level signal equalization None
Mechanical
Housing Metal enclosure Plastic molding
Dimensions
[L x W x H]
Model
93 x 60 x 25mm
[3.7” x 2.4” x 1”]
45 x 25 x 20mm
[1.8”x1”x0.8”]
Package
175 x 270 x 80mm
[6.9” x 10.6” x 3.1”]
115 x 170 x 40mm
[4.5”x 6.7”x1.6”]
Weight
Model 154g [5oz] 22g [0.8oz]
Package 455g [1 lb] 90g [3.2oz]
Fixedness Wall-mounting Direct plug-in
Power supply 5V 2A DC None
Power consumption 1 Watt [max] 0.5 Watt [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
Package Contents
1x HVE-9000
1x 5V power supply unit
1x User manual
1x HVE-9900
1x User manual
