Model Name HVE-9002 HVE-9003
Technical
Role of usage
1x2 distribution amplifier (splitter)
Transmitter [TX] Transceiver [TRX]
HDMI compliance HDMI 1.3c
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color depth
HDMI over UTP cable
transmission (24-bit)
Full HD (1080p) — 40m (130ft) [CAT5e] / 50m (165ft) [CAT6]
HD (720p/1080i) — 50m (165ft) [CAT5e] / 60m (200ft) [CAT6]
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Signal equalization None 8-level digital rotary control
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body — ±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset — ±8kV
Input 1x HDMI 1x RJ-45
Output
1x HDMI
1x RJ-45
1x 3.5mm audio socket
1x HDMI
1x RJ-45
1x 3.5mm audio socket
HDMI connector Type A [19-pin female]
RJ-45 connector WE/SS 8P8C with 2 LED indicators
3.5mm connector Earphone jack for stereo audio
DIP switch 2-pin DIP None
Rotary control switch None 8-level signal equalization
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H] Model 108 x 210 x 27mm [4.3” x 8.3” x 1.1”]
Package 200 x 330 x 95mm [7.9” x 1’1” x 3.7”]
Weight
Model 525g [1.2 lbs] 530g [1.2 lbs]
Package 980g [2.2 lbs] 985g [2.2 lbs]
Fixedness Wall-mounting
Power supply
5V 4A DC
Power consumption 3 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
Package Contents
1x HVE-9002 or HVE-9003
1x 5V power supply unit
1x User manual
