Model Name HVE-9001 HVE-9004 HVE-9008
Technical
Role of usage
Extender 1x4 splitter 1x9 splitter
Transmitter [TX]
HDMI compliance HDMI 1.3c
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color depth
HDMI over UTP cable
transmission (24-bit) Full HD (1080p) — 40m (130ft) [CAT5e] / 50m (165ft) [CAT6]
HD (720p/1080i) — 50m (165ft) [CAT5e] / 60m (200ft) [CAT6]
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Signal equalization None
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body — ±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset — ±8kV
Input 1x HDMI 1x HDMI 1x HDMI
Output 1x RJ-45 4x RJ-45
1x HDMI
8x RJ-45
HDMI connector Type A [19-pin female]
RJ-45 connector WE/SS 8P8C
DIP switch None 2-pin None
Rotary control switch Mode None Mode
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H]
Model
93 x 60 x 25mm
[3.7” x 2.4” x 1”]
215 x 85 x 40mm
[8.5” x 3.3” x 1.6”]
438 x 158 x 44mm
[1’5” x 6.2” x 1.7”]
Package
175 x 270 x 80mm
[6.9” x 10.6” x 3.1”]
330 x 200 x 95mm
[1’1” x 7.9” x 3.7”]
545 x 230 x 110mm
[1’10” x 9.1” x 4.3”]
Weight
Model 154g [5oz] 525 [1.2 lbs] 1.4kg [3.1 lbs]
Package 455g [1 lb] 985 [2.2 lbs] 2.2kg [4.8 lbs]
Fixedness Wall-mounting 1RU rack-mounting
Power supply 5V 2A DC 5V 4A DC
Power consumption 1 Watts [max] 10 Watts [max] 13 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
Package Contents
1x HVE-9001 / HVE-9004/ HVE-9008
1x 5V power supply unit
1x User manual
