1
Installation
Check the package contents against the list below.
Package Contents
1. FCS-1101
2. 6mm Fixed Lens
3. Camera Stand
4. CD Manual/Utility
5. Quick Installation Guide
Hardware Installation
Rear Panel：
Depending on the user’s application, an Ethernet cable may be needed. The Ethernet cable
should meet the specs of UTP Category 5 and not exceed 100 meters in length.
Connect the power adapter jack to the Network Camera before plugging in to the power
socket. This will reduce the risk of accidental electric shock.
Since FCS-1101 is a PoE IP camera, it could work without attaching to power outlet as long
Fixed Iris Lens
Body
Audio In
Audio Out
Reset
Power In
Network
