System Status Verification
The UTS system status and the status of up to three power sources can be viewed by pressing the System Status button
located on the front of the UTS. To navigate through the system status menus, press the System Status button after
viewing the information on the LCD.
LCD displays the input voltages from the UTILITY through the main
load center for PHASE1 and PHASE2.
LCD displays the SYSTEM LOAD (total power), that is being drawn through the
UTS AND the power drawn by each phase - PH1 and PH2
This information provides verification that the phases are balanced.
LCD displays the BACKUP1 source voltages for GEN PHASE1 and GEN PHASE2.
LCD displays the BACKUP1 source power outputs for GEN PHASE1
and GEN PHASE2.
LCD displays the UPS VOLTAGE and UPS LOAD for the BACKUP2
source (normally a UPS).
LCD displays the MODEL# (model number), and SN# (serial number)
of the UTS.
LCD displays the FW VER (firmware version) installed in the UTS.
LCD displays the MFG DATE (date of manufacture) for the UTS.
Circuit status verification
The status of each circuit on the UTS can be viewed by pressing the Circuit Status button located on the front of the UTS.
To navigate through the circuits, press the Circuit Status button after viewing the status of each circuit.
Example: CK1SRC (circuit1 source) indicates the power source (utility power), plus the
status of circuit1: number of Amps, number of kWh, and number of Watts.
UTILITY PHASE1: 120V
UTILITY PHASE2: 120V
SYSTEM LOAD: 2400W
PH1: 1050W PH2: 1350W
GEN PHASE1: 117V
GEN PHASE2: 118V
GEN PHASE1: 480W
GEN PHASE2: 750W
UPS VOLTAGE: 120V
UPS POWER: 200W
MODEL#: UTS10BI
SN#: JB06008004272
UTS FW VER: 1
UI FW VER: 1
MFG DATE: xx/xx/xxxx
CK1SRC: UTILITY AMP: 1
KWH: 2:35 WATTS: 120
