Overview
78 MM701G User Manual
O
VERVIEW
The MM701G provides:
• fixed-rate or rate-adaptive, symmetric G.shdsl transmission up to 2.3 Mbps
• multiple session types:
– PPP over ATM (RFC 2364)
– RFC 1483 bridging over ATM AAL5
– RFC 1483 routing over ATM AAL5 (IPoA)
• 32 simultaneous sessions of the same or different types
• support for point-to-point LAN extension
• DHCP (client and server) for sending and receiving dynamic IP addresses
• NAT (including NAPT) for IP address and port translation
• TFTP for modem software updates
• RIP versions 1 and 2 for dynamic IP routing information exchange
• multiple management options:
– serial interface
– telnet
– Web interface
– SNMP agent
• 10Base-T LAN interface with MDI/MDI-X switch
• front panel LEDs for troubleshooting and monitoring LAN and DSL connections
• PAP and CHAP for PPP login name and password authentication
• ATM Quality of Service selection
• statistics for monitoring network traffic
• diagnostic tests to assist technical support personnel
