Chapter 4: Managing the Modem Using the Console Port & Telnet
MM701G User Manual
51
M
ANAGING
DSL
Use the
G.SHDSL
menu to manage the DSL line. This menu allows you to:
•
view the DSL configuration
•
configure the DSL line
•
monitor the DSL statistics
•
test the DSL line
Viewing the DSL Configuration
1
From the
Main Menu
, select
DSL
by typing
3
to access the
G.SHDSL Menu
.
2
From the
G.SHDSL Menu
, select
G.SHDSL Current Settings
by typing
1
to access the
G.SHDSL
Current Setting
page.
3
View the DSL configuration as described by the table shown in
.
Configuring the DSL Line
1
From the
Main Menu
, select
DSL
by typing
3
to access the
G.SHDSL Menu
.
2
From the
G.SHDSL Menu
, do one of the following:
•
To configure Annex A or Annex B as the standard, select
Quick Configuration Setting
and
proceed to
“Quick Configuration” on page 52
.
•
To configure the advanced features of the modem, select
Advance Configuration Setting
and proceed to
“Advanced Configuration” on page 52
G.SHDSL Menu
1. G.SHDSL Current Settings
2. Quick Configuration Setting
3. Advance Configuration Setting
4. G.SHDSL Statistics
5. Hardware/Line Diagnostics
Enter Selection (Return to exit) ->
