26
Position Setting
Window
Position/Velocity
Acceleration
/Deceleration
Acceleration
/Deceleration
Energy-
Saving
Position Data Position Acceleration Acceleration Deceleration
Pressing
Force
Pressing
Width
Energy-Saving
Function
0 Backward
Position
0.00 50.00 0.1 0.1 0 0 Effective
1 Forward
Position
200.00 50.00 0.1 0.1 70 1.00 Effective
2 Backward
Position
10.00 50.00 0.1 0.1 0 0 Effective
3 Forward
Position
100.00 50.00 0.1 0.1 60 1.00 Effective
[2] Position Setting Window Types
[Position/Velocity setting]
The Position and Velocity are set here.
[Pressing setting]
The Pressing Force and Pressing Width are set here.
Touching PUSH in the “Positing/Velocity setting” window displays the “Pressing setting”
window.
[Acceleration/deceleration setting]
The Acceleration and Deceleration are set here.
Touching ACC in the “Position/Velocity setting” window displays the “Acceleration/deceleration
setting” window.
