15
LP- 204 REV. 3.25.14

Have water supply tested and ensure it meets the requirements outlined in the Part 2, Section E of this manual
Relief Valve

Temperature and Pressure relief valve properly installed and discharge line runs to open drain

Discharge line not exposed to freezing temperatures

Discharge line constructed of copper
Wiring

Power supply voltage agrees with the water heater rating plate

Branch circuit wire fusing or circuit breaker properly sized

Electrical connections tight and properly grounded

Water heater control is secure and in control well
Solar Heat Exchanger to Solar Panel

Anti-freeze (if used) is added and rated as non-toxic with copy of MSDS sheet for homeowner

Solar heat exchanger completely purged of air

Expansion tank and temperature and pressure gauge operating properly

Solar control shows circulators operating properly on the solar panels
Anti-Freeze Fluid (if used in system)

Make sure freeze protection fluids are certified non-toxic, FDA rated GRAS

Glycol percentage must be calculated per local area freeze level

Provide glycol MSDS sheet to end user
NOTE: Make sure you have all necessary tools, materials and accessories before beginning work on the solar system.
TOOLS AND MATERIALS
Electric Drill
Torch and Striker
Drill Index (w/ ½”, ¾”, 1” and 1 ¼” Wood Bits) Putty Knife
Hack Saw High Temperature Joint Compound
Tubing Cutter Wire Nuts or Connectors
Tin Snips Miscellaneous Copper Pipe & Fittings (3/4”)
16’ Tape Measure 1” x ¾” Copper Sweat Couplings
24” Level 1” Copper Sweat Caps
Flashlight Silicon Caulk and Roof Sealant
Extension Cord Minimum ¾” I.D. Type M Copper Tubing
Slip Joint Pliers Needle Nose Pliers
Pipe Wrenches, 10” and 14” Angle Iron
Open End Wrenches, 9/16 & 7/16 Threaded Rod, Nuts, & Washers
Screw Driver 6” Flat Blade Stainless Screw Clamps
Screw Driver 6” Philips Thermal Adhesive
Wire Stripper or Knife Aluminum Flashing Sheet
Wire Cutters Black Latex Outdoor Paint
Adjustable Wrenches 8” & 10” 7/8” x ¾” and 1 1/8” x ¾” pipe insulation
Solder Flux Emory Paper
B. SOLAR WATER HEATER LOCATION
To minimize expense and heat loss, locate the solar water heater as centrally to the domestic piping system and near the solar
collectors as possible. The water heater must also be located in an area where it will not be exposed to freezing temperatures. All
piping should be insulated to protect against freezing and heat loss.
In addition, the solar water heater and all related solar system components should be installed with plenty of clearance for inspection
and service. If minimum clearances are not met, it may not be possible to service the solar system without removing component parts
from installation locations.
The solar water heater should also be installed in a place where T&P discharge or a leak will not result in damage to the surrounding
area. Install a 2” high catch pan with a minimum of ¾” drain line to prevent water damage if leakage should occur (see Figure 5).
