14
NUMBER DEFINITION
12 S1 temperature high
13 S2 temperature high
14 Flue temperature high
16 Regulation temperature high
17 Not enough water flow
21 Anti-cycling CH
23 max flue pressure switch/ max start cycles
25 Max temperature increase limiting CH
26 24 V to low
30 Water level low 1
31 Water level high 1
32 Water level low 2
33 Water level high 2
Table 11
D. LOCKOUT CODES
LOCKOUT CODES (INPUT REGISTERS 30016, 30025, 30029, 30033, 30037, 30041, 30045, AND 30049)
NUMBER DEFINITION
240 Flue thermostat open
239 Safety thermostat open
237 False Flame
236 APS stuck open
235 APS stuck closed
233 No flame after ignition
232 No flame during running
230 Fan fault
204 Parameters damaged
205 Parameters programmed
206 Error during programming
207 Parameter EEPROM failure
190 S1 maximum temperature
191 S2 maximum temperature
192 S1 shorted
193 S1 interrupted
194 S2 shorted
195 S2 interrupted
196 Low water lockout
197 Flue sensor shorted
198 Flue sensor interrupted
199 Low water lockout 2
185 ECS6 temperature lockout
186 ECS7 temperature lockout
Table 12
E. STATUS CODES
STATUS CODES (INPUT REGISTERS 30014, 30023, 30028, 30032, 30036, 30040, 30044, AND 30048)
NUMBER DEFINITION
0 Standby
96 Running
100 DHW Mode or Blocking for Cascade
101 Low Water Blocking
Table 13
F. CONFIGURATION BITS
Address 40001 contains configuration bits sent from the BAS to the appliance. These bits tell the appliance to use its own internal
inputs, or inputs from the BAS. When a bit is set to 1, the appliance will ignore the corresponding value contained internally and expect
the BAS to write that value into the holding registers.
The configuration bits are as follows:
