Harrington Hoists and Cranes AHM Hoist User Manual
Page 53
Manipulator Control
53
Figure
Number
Name
Parts
Per
Hoist
Part Number
12M
Chain Basket CP
1
AH42621592C
17
Bucket Arm Assembly (pair)
1 pr.
AH426205920
18
Arm Holder
2
AH426205820
19
Bolt
1
90933177
20
U-Nut
2
E2D853125
21
Washer
1
9012510
22
Chain Basket
1
AH139003026
23
Socket Bolt
1
9091239
200
Hose Arm
1
AH426215960
201
Hanger Half
4
AH426215B30
202
Coil Hose – Std. 6.5 ft lift
1
AH137202018
Coil Hose – Opt. 13 ft lift
1
AH137202019
203
Rubber Bushing
2
AH136608252
204
Hose Support
1
AH136608253
205
Tube Fitting
1
AH137289310
206
Tube Fitting
5
AH137290310
207
Socket Bolt
4
9091229
208
Socket Bolt
2
9091227
219
Throttle Valve Complete
1
AH42621597D
220
Throttle Valve
2
AH420215VB0
221
Push Rod
2
AH420215VC0
222
O-Ring
2
AH131118012
223
O-Ring
2
AH131117013
224
Throttle Valve Body CP
1
AH42621597B
225
Lever Pin
1
AH130402048
226
Throttle Lever Up
1
AH420985UY0
227
Throttle Lever Down
1
AH420985UZ0
228
Valve Spring
2
AH130802221
229
Spring Seat
2
AH426215B00
230
O-Ring
2
AH131103016
231
Retaining Ring
2
9047224
234
Grip
1
AH136608140
241
Retaining Ring
2
AH130303004
232
Rotary Joint
1
AH426215B40
233
Hook Protector
1
AH136201200
236
Rubber Bushing
1
AH136608251
237
O-Ring
8
AH131103013
238
O-Ring
1
AH131101015
239
Button Head Screw
5
AH131905030
Figure
Number
Name
Parts
Per
Hoist
Part Number
240
Button Head Screw
1
AH131905060
242
Spring Pin
2
9148123
290
Shield
1
AH426215B20
291
Hex Socket Pipe Plug
2
AH134901006
292
Manipulator Warning Tag
1
AH137304071
