10
Table 2-4 Pendant Model Speeds, ft/min at 90 psi*
Capacity
(lbs.)
Product Code
UP DOWN
Full Load No Load Full Load No Load
250 AH250P 42 (33) 55 (48) 48 (45) 43 (38)
500 AH500P 29 (18) 55 (48) 53 (51) 43 (38)
Table 2-5 Pendant Model Air Consumption, CFM at 90 psi*
Capacity
(lbs.)
Product Code
UP DOWN
Full Load No Load Full Load No Load
250 AH250P 28 (21) 31 (24) 27 (21) 26 (20)
500 AH500P 26 (19) 31 (24) 28 (22) 26 (20)
* Values in parentheses for air supply at 60 psi.
Figure 2-2 Dimensions for Pendant Model Mini-Cat Air Hoist (inches)
