Valve Body
51
Figure
Number
Name
Parts
Per
Hoist
Part Number
1
Main Spool
1
AH426205010
2
Valve Bush
1
AH426205780
3
Shuttle
1
AH426205870
4
Valve Seat R
1
AH426205830
5
Valve Seat L
1
AH426205840
7
Side Cover
2
AH426205080
8
Valve Pin
1
AH426205850
9
Limit Lever
1
AH426205140
10
Limit Guide
1
AH426205100
11
Limit Shaft
1
AH426205460
12
Chain Lever
1
AH426205110
13
Stopper
1
AH426205860
14
Under Cover
1
AH426205470
15
Exhaust Plate
1
AH426205810
16
Valve Packing
1
AH136102151
17
Under Packing
1
AH136102153
18
Silencer S
4
AH137402022
19
Silencer F
1
AH137402021
21
Bumper
2
AH136406025
22
Protector
1
AH426205880
23
O-Ring
2
AH131117004
24
O-Ring
2
AH131103003
25
O-Ring
4
AH131103014
26
O-Ring
2
AH131103016
27
Socket Bolt
1
9091209
28
Socket Bolt
2
9091210
29
Button Head Screw
2
AH131905008
30
Button Head Screw
1
AH131904008
31
Hex Flat Head Machine Screw
6
AH132804010
32
Set Screw
2
AH132110008
33
Set Screw
3
AH132104005
35
Washer
1
9012513
36
Washer
1
9012510
37
Retaining Ring
2
9047222
38
Hair Pin Cotter
1
AH130790008
39
Parallel Pin
3
AH130406017
40
Spring Pin
1
9148116
170
Hose Stem
1
AH134803040
171
Inlet Bushing w/Screen
1
AH134703050
Pendant and Manipulator Models Only:
Figure
Number
Name
Parts
Per
Hoist
Part Number
6
Valve Body
1
AH426206060
20
Valve Spring
1
AH130802209
160
Manifold Block
1
AH426206941
164
O-Ring
2
TCR131103008
165
Socket Bolt
2
9091232
166
Spring Pin
2
9148123
Cord Model Only:
Figure
Number
Name
Parts
Per
Hoist
Part Number
6
Valve Body
1
AH426205060
20
Valve Spring
1
AH130802208
34
Hex Socket Pipe Plug
1
TCR134902003
160
S-Type Wire
2
TCR130802081
161R
Red Cord (Down)
ft (m)
9013102
161W
White Cord (Up)
ft (m)
9013101
163
Grip W
1
AH136602625
164
Grip R
1
AH136602626
165
Handle
1
AH136602627
Pendant Model Only:
Figure
Number
Name
Parts
Per
Hoist
Part Number
153
Pendant Hose Assy.
(Three hoses)
1
60472
155
Cord Chain
ft (m)
ES625003
156
Eye Bolt
1
9044403
157
Eye Bolt
1
9044401
158
Split Ring
A/R
AH130802093
159
S-Type Wire
2
TCR130802081
161
Boot
2
AH136608250
163
Hose
3
@
ft
(m)
9013141
169
Warning Tag
1
WTAG7
162
Hose Fittings
6
AH137291310
154
Pendant Tube Assy.
(Molded Tubing)
1
60471
161
Boot
2
AH136608250
163
Pendant Hose
ft (m)
AH1372400HS
169
Warning Tag
1
WTAG7
162
Tube Fitting
6
AH137288030
167
Pendant Valve CP
1
AH420215VBC
167A
Throttle Valve
2
AH420215VB0
167B
Push Rod
2
AH420215VC0
167C
O-Ring
2
AH131118012
167D
O-Ring
2
AH131117013
167E
Pendant Valve Body CP
1
AH420215VRB
167EA Pendant Valve Body
1
AH420215VR0
167EB Bushing
2
AH420214VF0
167F
O-Ring
2
AH131103016
167G
Spring Pin
2
9148176
167H
Pendant Valve Lever
2
AH420210VH0
167J
Valve Spring
2
AH130802030
167K
Pendant Valve Cap
2
AH420214V10
167L
O-Ring
2
TCR131103022
167M
E-Ring
2
AH130303004
