22
Standard Alternate/Extended
Figure 3-9 Manipulator Model’s Bottom Hook Position
3.14 Preoperation Checks and Trial Operation
3.14.1

Confirm the adequacy of the rated capacity for all slings, chains, wire ropes and all
other lifting attachments before use. Inspect all load suspension members for damage prior to use and
replace or repair all damaged parts.
3.14.2

Verify that the no-load end of the load chain is attached to the hoist body. For
reference see Figure 7-3.
3.14.3 Measure and record the “K” and “U” dimensions for the top and bottom hooks. See Table 5-6 under
Section 5, “Inspection”.
3.14.4 Record the hoist Code and Serial Number (from the name plate on the hoist – see Figure 10-1) in the
space provided on the cover of this manual.
3.14.5 Ensure that the hoist is properly installed to either a fixed point, or trolley, whichever applies.
