Harrington Hoists and Cranes CB Hand Chain Hoist - Manual (Page 52)

52
9.4 Optional Hooks
Shur-Loc
®
Hooks
Fig. No. Name
Parts
Per
Hoist
½T 1T 1½T 2T 2½T 3T
1
Shur-Loc ® Top Hook
Complete Set
1 6030201 6030202 6030203 6030204 6030205
2
Shur-Loc ® Hook
Assembly
1 60140 60142 60144 60145 60146
3 Top Yoke Kit 1 TYKITCB005 TYKITCB010 TYKITCB015 TYKITCB020 TYKITCB025
4 Button Head Screw 2 9012612 9012602
5 Flexloc ® Nut** 2 9012613 9012604
6 Warning Tag 1 WTAG6*
7
Shur-Loc ® Bottom Hook
Complete Set
1 6030101 6030102 6030103 6030104 6030106 6030107
8
Shur-Loc ® Hook
Assembly
1 60140 60142 60144 60145 60146 60148
9 Bottom Yoke Kit 1 BYKITCB005 BYKITCB010 BYKITCB015 BYKITCB020 BYKITCB025
10 Button Head Screw 4 9012612 9012602
11 Flexloc ® Nut** 4 9012613 9012604
12 Warning Tag 1 WTAG6*
*Hoist with Shur-Loc ® Hook(s) must have WTAG6 and WTAG9 installed. (See page 6 for WTAG9).
**See Table 6- 3 in Owner’s Manual for yoke nut torque specifications.
Inspection Hooks
Fig. No. Name
Parts
Per
Hoist
½ T 1T 1½T 2T 2½T
1
Top Hook Complete
Set
1 M3001A005IK M3001A010IK M3001A015IK M3001A020IK M3001A025IK
2 Hook W/Latch & Yoke 1 M3001A005IH M3001A010IH M3001A015IH M3001A020IH M3001A025IH
3 Button Head Screw 2 9012612 9012602
4 Flexloc ® Nut* 2 9012613 9012604
6
Bottom Hook Complete
Set
1 M3021A005IK M3021A010IK M3021A015IK M3021A020IK M3021A025IK
7 Hook W/Latch & Yoke 1 M3021A005IH M3021A010IH M3021A015IH M3021A020IH M3021A025IH
8 Button Head Screw 2 9012612 9012602
9 Flexloc ® Nut* 2 9012613 9012604
*See Table 6- 3 in Owner’s Manual for yoke nut torque specifications.
