47
9.2 3 to 20 Ton Parts
Fig.
No.
Part Name
Qty
per
Hoist
Capacity (T)
3 5 8 10 15 20
51 End Pin 1 M3B164100
52 Split Pin 1 9009415-5
53 Cross Guide 1 M3B176100
54 Top Hook Set
1 M3001A030 M3001A050 M3001A075 M3001A100 M3001A150
2 M3001A200
55
Top Hook 1 M3001150 M3001200
Top Hook Ass’y 1 L42001090
56 Latch Assembly 1 CF071030 M3072050 L41071090 M3072150 M3072200
57
Idle Sheave
Ass’y
1 M3051050
2 M31051150
3 M31051150
58 Shaft Assembly 1 M3053050
59A Top Yoke A 1 M3011075 M3011100 M3016150
59B Top Yoke B 1 M3012075 M3012100 M3017150
60 Socket Bolt
3 90912116
1 90912116
61 Lever Nut
3 L4082090
1 L4082090
- Socket Bolt 2 M3086100
- U-Nut 2 9098516
62 Top Susp. Shaft 2 M3010150 M3010200
63 Top Yoke 2 M3011200
64
Top Plate A
Assembly 1 M35012150
2 M35012200
- Top Plate B 1 M3014150
65 Guide
4 M3018150
6 M3018150
66 Stay Bolt 2 M3019150 M3019200
- Top Plate 1 M3043150
67 Top Shaft 1 M3053150 M3053200
68 Key Plate 2 M2056150
- Collar 2 M3066150
70 Socket Bolt 4 9091270
71 Nut 4 9093458
72 Nut 4 9093445
73 Spring Washer 4 9012711
74 Spring Washer 4 9012717
75 Spring Washer 4 9012721
