Sonnet AV/HPV Card Video Adapter Kit
6
Figure 25: Verify cover aligns with support runner
Figure 26: Finish sliding case cover onto computer
23. Make certain the cover lines up with the support runner of the
computer’s case (Figure 25). The video adapter board should be firmly
in place and not misaligned with the access port slot. If the video
adapter board appears “tweaked” you will need to carefully realign the
case back onto the computer.
24. Finish sliding the cover onto the computer until it lines up with
the rear of the computer (Figure 26).
25. Once the cover is in place, tighten the security screw on the back of
computer’s case.
26. Reconnect the power and peripheral cables to the computer.
27. Turn on your Power Macintosh. Your newly accelerated machine should
boot as normal.
cover should align with support runner
adapter board should be firmly in place
