Sonnet Technologies Tempo SSD PCI Express 2.5 SSD Host Card - Manual (Page 7)

5
SSD Installation Steps
Dual SSD Installation (continued)
8. Flip the card/plate assembly over again, and
then place the second SSD label side up on
top of the extension plate with the SSD’s and
card’s connectors aligned with each other
(Figure 7).
9. Push the SSD’s connector into the Tempo SSD
card’s connector until the SSD is completely
seated
(Figure 7).
10. Holding the SSD firmly against the plate, flip
the assembly over again.
11. Using the remaining four screws you
removed previously, secure the SSD to the
extension plate; do not overtighten the screws
(Figure 8).
Figure 7
Figure 8
