Quick Start Guide for Tempo SATA X4i
About Tempo SATA X4i’s Ports and LEDs
1. Each SATA connector on the Tempo card is assigned a channel number
that may be helpful if you need to diagnose any issues (Figure 12).
2. When drives connected to the Tempo card are powered and active, the
status LEDs on the card will light (Figure 13):
• Green LED ON: Drive(s) present and ready.
• Amber LED ON/Flashing: Drive(s) reading/writing data.
Figure 12
Figure 13
channel 4
channel 3
channel 2
channel 1
green LEDs
amber LEDs
