Check for parts online at www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5 16
Operator's Manual
Rivers Edge® Two-Man Ladder Stands
kEY # PART # DESCRIPTION QTY.
1 10321 RAIL J PIPE Foot PLAtFoRM 2
2 10322 WELdMENt SIdE SEAt SUPPoRt LooP 2
3 10323 WELdMENt tREE BLAdE 2 MAN LAddER 1
4 10325 RIM BACKRESt 2 MAN LAddER 1
5 10326 tUBE SHootINg RAIL RECEIVER 2
6 10327 RIM SHootINg RAIL 2 MAN LAddER 1
7 10328 MoUNt tAB SHootINg RAIL StoP 2
8 10329 StRIP FABRIC MoUNt 812 MM 2
9 10330 WELdMENt FtS MESH SEAt FRAME 2
MAN
1
10 10347 SPACER NYLoN 1/4 x 1 x 1/2 8
11 1ML23 TUBE, STABILIZER, SUPPORT 1
12 2ML130 WELdMENt, tREE BLAdE 1
13 2ML133 WELdMENt, Foot PLAtFoRM, 2-MAN
LADDER
2
14 2ML46 tUBE, 2-MAN SUPPoRt 2
15 48240B BoLt 1/4-20 x 1-1/2 HHCS gR5 BLK ZN 22
16 48261B WASHER 1/4 BLK ZNC 26
17 48270B BoLt 1/4-20 x 2-1/2 HHCS gR5 BLK ZN 6
18 48271B BoLt 1/4-20 x 2-1/4 HHCS gR5 BLK ZN 14
19 48679 RUBBER BUMPER STOP 4
20 48752B NUt 1/4-20 HFNYLK BLK ZN 50
kEY # PART # DESCRIPTION QTY.
21 63281 SNAP PIN, 1/4 x 1-3/4, RoUNdEd
REtAINER
8
22 67540B BoLt 1/4-20 x 2-3/4 HHCS gR5 BLK ZN 8
23 L17 WELdMENt, StABILIZER BAR 1
24 LL9A LADDER PLATFORM BRACE 2
25 SL51 WELdMENt,LAddER, 4-StEP, PoCKEt/
PIN StYLE
1
26 SL52 WELdMENt,LAddER, 4-StEP W/VAM,
PoCKEt/PIN StYLE
1
27 SL54 WELdMENt,LAddER W/HoLES 4-StEP,
PoCKEt/PIN StYLE
1
ITEMS NOT ShOWN
-- 48415 RATCHET STRAP 2
-- 48155 FULL BodY HARNESS (FAS) 2
-- 48691 tIE-oFF RoPE KIt (INCLUdES tWo 15'
RoPES ANd oNE 9' RoPE)
1
-- 48800 dVd tREEStANd SAFEtY 1
-- 10332 ASSEMBLY SEAT TWOPLEX 1
-- 48736 9" CAMO SLEEVE 2
-- 48739 36" CAMO SLEEVE 1
RE633 PARTS lIST
Maximum height - 17' 7" to shooting rail
Maximum field Rating - 500 lbs; no more than
300 lbs per person.
Tree Diameter Range - 12" to 20"
NO EXTENSIONS AvAIlABlE fOR ThIS MODEl.
NEvER MODIfY OR EXCEED ORIGINAl STATED uSE hEIGhT!
