Operator's Manual
Rivers Edge® One-Man Ladder Stands
kEY # PART # DEsCRIPTION QTY.
1 10336 TUBE BRACE UPPER LADDER SUP-
PORT
2
2 10338 RAIL SIdE FLAREd LAddER 40.48 IN 2
3 10340 WELdMENT PLATFoRM 18 1/4 IN x
12 IN
1
4 10343 BRACE doUBLE FLAT 21.36 IN 2
5 10344 WELdMENT TREE BLAdE LAddER 1
6 10346 TUBE RAIL SIDE LADDER 2
7 10368 BOLT 1/4-20 X 2-1/4" PTH GR 5 BLACK
ZINC
4
8 10468 WELdMENT LAddER 3 STEP PIN
STYLE
2
9 10470 WELdMENT LAddER 3 STEP PIN STyLE
W/vAM
1
10 1ML23 TUBE, STABILIzER, SUPPORT 1
11 410034 STEP LADDER 17" 1
12 410044 WELdMENT BASE ExTENSIoN 1
13 48153B BoLT 1/4-20 x 2 HHCS gR5 BLk ZN 2
14 48240B BoLT 1/4-20 x 1-1/2 HHCS gR5 BLk ZN 6
15 48261B WASHER FLAT 1/4" BLACK 18
16 48271B BoLT 1/4-20 x 2-1/4 HHCS gR5 BLk ZN 12
17 48752B NUT 1/4-20 HFNyLk BLk ZN 26
18 63281 SNAP PIN, 1/4 x 1-3/4, RoUNdEd
RETAINER
10
19 L17 WELdMENT, STABILIZER BAR 1
20 48270B BoLT 1/4-20 x 2-1/2 HHCS gR5 BLk ZN 2
ITEMs NOT shOWN
-- 48415 RATCHET STRAP 1
-- 48155 FULL Body HARNESS (FAS) 1
-- 48736 CAMO SLEEvE W/FOAM 9" 2
-- 48691 TIE-oFF RoPE kIT (INCLUdES TWo 15'
RoPES ANd oNE 9' RoPE)
1
-- 10542 ASSEMBLY SEAT RELAX 1
-- 48800 dVd TREESTANd SAFETy 1
RE630 PARTs lIsT
Maximum height - 16' 1" to armrests
Maximum field Rating - 300 lbs.
Tree Diameter Range - 12" to 20"
NO EXTENsIONs AvAIlABlE fOR ThIs MODEl.
NEvER MODIfY OR EXCEED ORIGINAl sTATED usE hEIGhT!
