Page 23
Check for parts online at
www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5
23
Operator's Manual
Rivers Edge® One-Man Ladder Stands
kEY #
PART #
DEsCRIPTION
QTY.
1
10347
SPACER NyLoN 1/4 x 1 x 1/2
2
2
1ML23
TUBE, STABILIzER, SUPPORT
1
3
1ML40
BRACE, SUPPORT FLAT, TIMBER LADDERS
2
4
410024
BRACE SUPPORT 35.69"
2
5
410034
STEP LADDER 17"
1
6
410053
RAIL SIDE LADDER
2
7
410055
RAIL PLATFORM SUPPORT
2
8
410062L WELdMENT ARMREST LEFT
1
9
410062R WELdMENT ARMREST RIgHT
1
10
410066
WELdMENT LAddER 3 STEP
1
11
410068
WELdMENT LAddER W/MoUNT 3
STEP
1
12
410069
WELdMENT LAddER W/HoLES 3 STEP
1
13
410081
STRIP FABRIC MoUNT
2
14
410082
FTS MoUNT BACkREST
2
15
410083
WELdMENT PLATFoRM FRoNT 26"
X 15"
1
16
410086
WELdMENT PLATFoRM REAR 26" x 15"
1
17
410089
RAIL SIDE FLARED LADDER
2
18
410090
WELdMENT, TREE BLAdE LAddER
1
19
410092
FTS FOOTREST LADDER
1
20
410093
WELdMENT FTS SHooTINg RAIL
1
21
410113
FTS J PIPE SHooTINg RAIL
2
22
410115
ASSEMBLy SEAT SPACER FRoNT
1
23
410119
WELdMENT SPACER BACkREST
1
24
410127
WELdMENT SEAT SPACER REAR
1
kEY #
PART #
DEsCRIPTION
QTY.
25
48153B
BoLT 1/4-20 x 2 HHCS gR5 BLk ZN
6
26
48240B
BoLT 1/4-20 x 1-1/2 HHCS gR5 BLk ZN
16
27
48261B
WASHER FLAT 1/4" BLACK
32
28
48271B
BoLT 1/4-20 x 2-1/4 HHCS gR5 BLk ZN
20
29
48280B
BoLT 1/4-20 x 3 HHCS gR5 BLk ZN
2
30
48752B
NUT 1/4-20 HFNyLk BLk ZN
50
31
63281
SNAP PIN, 1/4 x 1-3/4, RoUNdEd
RETAINER
8
32
67540B
BoLT 1/4-20 x 2-3/4 HHCS gR5 BLk ZN
2
33
8909B
BoLT 1/4-20 x 1-1/4 HHCS gR5 BLk ZN
4
34
L17
WELdMENT, STABILIZER BAR
1
35
WN516
WASHER, 5/16", BLACk NyLoN
2
36
10755
NUT 3/8-16 HEx BLk ZINC
1
37
719
WASHER 3/8" SPRINg LoCk ZINC
1
ITEMs NOT shOWN
--
360019
ASSEMBLY SEAT JUMBO JACK
1
--
360022
ASSEMBLY BACKREST JUMBO JACK
1
--
48415
RATCHET STRAP
1
--
48155
FULL Body HARNESS (FAS)
1
--
48736
CAMO SLEEvE W/FOAM 9"
2
--
48913
CAMO SLEEvE W/FOAM 54"
1
--
48691
TIE-oFF RoPE kIT (INCLUdES TWo 15'
RoPES ANd oNE 9' RoPE)
1
--
48102
PAD, BUMPER SEAT
2
--
48800
dVd TREESTANd SAFETy
1
RE628 PARTs lIsT
Maximum height - 17' 2" to shooting rail
Maximum field Rating - 300 lbs.
Tree Diameter Range - 12" to 20"
NO EXTENsIONs AvAIlABlE fOR ThIs MODEl.
NEvER MODIfY OR EXCEED ORIGINAl sTATED usE hEIGhT!
