Air Requirements:

70-100 psig (4.8-6.9 bar)

Operating Pressure

Air Inlet/Outlet

Connections:

1/4-inch OD Tubing

Fluid Pressure:

300 psig (20.6 bar)

maximum

Fluid Inlet:

1/4-inch NPT(F) X 2 port

(Fitting installed 3/8-

inch OD tubing)

Fluid Outlet:

1/4-inch NPT(F) X 1 port

(Fitting installed 3/8-

inch OD tubing)

Fluid Flow Capacity:

3800 cc/min @ 47 psi

pressure drop (Paint

viscosity @ 700

entipoise)Varies

according to material

pressure and viscosity.

Valve Actuation

Speed, On-Off Cyle:

55 cycles/min

Colors:

Up to and including 30 colors total.

INTRODUCTION

SPECIFICATIONS

Nominal

Dimensions:

See “Color Valve Stack

Figure” in the “Parts

Identification” section.

DESCRIPTION

CCV-5100 Color Valve Stack

The

CCV-5100 Color Valve Stack is a manually

controlled pneumatic color change valve assem-

bly. The stack allows for up to and including 30

different colors. Color changes are made using

CCV-403-SS color change valves.

CCV-403-SS Color Valve Stack

The

CCV-403-SS Color Valve Stack is a pneu-

matically operated fluid valve designed for use in

paint spray application systems. The valve can be

used in a variety of other applications. The valve

can be used separately for on/off control of paint

to a spray atomizer; or, as part of a multi-color

manifold assembly where colors can be quickly

flushed and changed when a color change is de-

sired. The CCV-403-SS includes a red indicator

(visible through holes in the valve body) that can

be seen when the valve is turned “on.”

All parts that come in contact with the fluid material

are made of either stainless steel or that is imper-

vious to most solvents. All other parts of the valve

are made of brass, stainless steel, nickel-plated

brass, or hard coated (anodized) aluminum. The

valve is constructed with a smooth, unobstructed

fluid path that allows for faster flush cleaning, and

also less pressure restriction. The valve body

has two fluid inlet ports that allow fluid to circulate

through the valve on a continuous basis. A plug

is provided when this feature is not to be used.

The double inlet ports also allow two valves to be

used as a fluid on/off control and dump system.

* If CCV valve is used for “Air Push” air leakage

may occur if pressure is excessive.

Environmental/Physical

Mechanical

6

Color Valve Stack - Introductions

LN-9113-06.3
