1 ---- Air Inlet, 1/8” NPT (F)
2 CCV-45 Clamping Nut *
3 VA-246 Cup *
4 CCV-3 Nut
5 CCV-41-K2 Spring Kit
6 CCV-4 Spring Washer
7 CCV-8-K2 Valve Needle Seal Kit *
8 ---- Fluid Inlet (2 ports), 1/4” NPT (F)
9 CCV-13 Spanner Nut
10 CCV-44 Ring Retainer
11 SST-8436-K5 Retaining Ring Kit
12 CCV-40-K2 Poppet Seat Kit *
13 CCV-39 Stem (Order KK-4841) *
14 SSP-1421 Pipe Plug (Shipped loose with valve)
(Not used if material is recirculated)
15 CCV-15-SS Valve Body
16 CCV-42 Valve Indicator
17 CCV-43 Valve Cap
18 ---- Use adhesive (Medium Strength, Grade #242) on threads - 2 places
19 ---- Apply a thin film of lubricant (light grease) to bore and cup at
assembly.
-- CCV-7 Spanner Tool (Not Shown)
Item #
CCV-403-SS CUTAWAY - PARTS LIST (Figure 6)
Part # Description
* Supplied in Repair Kit KK-4841.
Note: Tighten CCV-45 to CCV-3 with VA-246 in between, using 12-18 lbs.•in torque.
Tighten CCV-45, CCV-3, VA-246 assembly to CCV-39 using 3 lbs•in torque maximum (finger
tight). Do Not Over-Tighten.
Paint Manifold Assembly Kit
ACCESSORIES
KK-4901
Part # Description
21
Color Valve Stack - Parts Identification
LN-9113-06.3
