OPERATION
Installation and Operation
Overview
The coating material is supplied from the users
pressurized system that may be a pressure tank,
paint circulating system or other suitable pressure
paint supply system. 3/8-inch OD fluid tubing is
connected between the users paint supply and
the CCV.
An air signal supplied to the CCV activates the
paint being delivered to the applicator.
NOTES
> CCV Valve must be supported while
tightening the tube fittings to prevent
damage to the valve seats, or remove
the valve before tightening the fluid inlet
fittings.
> Circulation system lines must have
a flexible connection between the “hard
piping” and the valve.
C A U T I O N
!
