Make sure all seating surfaces of the
stem, poppet seat, needle seal, and cup
are clean and free of nicks and scratches
to prevent leakage.
NOTE
Manifold Reassembly
1. When reinstalling the CCV-403-SS back into
the manifold block or valve adapter, torque the
spanner nut to 132-156 lbs•in. Do not over-tight-
en.
2. If the manifold blocks are disassembled, do
not reuse o-ring 23165-430 which goes between
each block. Replace with new o-rings. Reusing
the old o-rings may cause leakage.
3. Torque the four SS-655-ZN nuts (which hold
the manifold blocks together) to 110-130 lbs•in.
4. When reinstalling air and fluid connections, use
a good quality pipe sealant on the threads. How-
ever, do not use sealant or tape on the spanner
nut threads when installing the CCV-403-SS valve
into the manifold block or valve adapter.
NOTES specifications shown in “CCV-403-SS Cutaway
Parts List Note” in the “Parts Identification” sec-
tion. Do not rotate the stem during assembly.
3. Apply a thin film of lubricant (light grease type)
to the valve cap bore and cup as shown in “Figure
6” in the “Parts Identification” section. Tighten
the valve cap to the torque specification shown
“CCV-403-SS Cutaway Parts List Note” in the
“Parts Identification” section.
13
Color Valve Stack - Maintenance
LN-9113-06.3
Ransburg
