Bit 14 - Over Current Fault
The current value has exceeded the
Current (I) Limit Hi or the Max System
Limit.
Bit 15 - Cable Fault
This bit is set whenever the voltage or
current feedback from the cascade has
been lost or fallen below the acceptable
value.
Output Word 2
Bits (0-7) - Parameter Data Value
This byte (8 bit) tells the system the
active parameter value.
Bits (8-14) - Parameter Select Code
This 7 bit value tells the system which
parameter is being displayed.
Bit 15 - Parameter Acknowledge
When this bit changes from cleared to
set a new Parameter Value is being dis-
played. It is cleared when the Parameter
Read Strobe and Parameter Write Strobe
are both cleared.
Output Word 3
Bits (0-7) - Actual kV Value
The byte (8 bit) value displays the latest
voltage reading in kV.
Bits (8-15) - Actual uA Value
This byte (8 bit) value displays the latest
current reading in uA.
