12.2 Output Zone/Channel Connections Table—For Trinity Multi
-zone
Either 9, or 12 output channel options are available for driving and
dimming LEDs. Channels are assigned to zones as shown in the following
tables. A 9 channel option will provide 9 zones for dimming and a 12
channel option will provide 12 zones for dimming.
Zone Number
Output Channel
Belden/Alpha or Equivalent Wire Color/
Polarity
1
1
WHT + / BLK -
2
2
RED
+ / BLK -
3
3
GREEN
+ / BLK -
4
4
WHT + / BLK -
5
5
RED
+ / BLK -
6
6
GREEN
+ / BLK -
7
7
WHT + / BLK -
8
8
RED
+ / BLK -
9
9
GREEN
+ / BLK -
10
10
WHT + / BLK -
11
11
RED
+ / BLK -
12
12
GREEN
+ / BLK -
9/12 Channel - Zone Connection Table
12.3 Multi-zone Analog Interface Specification and Cabling
Connections
Trinity Multi-zone Analog uses the same interface and cabling
specifications as Trinity Analog. See sections 11.3 and 11.4 for
requirements.
