Trinity PC DMX Specifications
Input
Output
System Protection
Safety and EMI/EMC
Environmental
Control Interface
Rated Input Voltage 115 to 125 Vac
Rated Input Frequency 47 - 63 Hz
Power Factor EN61000-3-2 @ 115 Vac, 100% load, 0.97 W/VA min
Input Current Total Harmonic Distortion @ 115 Vac, 100% load, 13% max
Rated Output Power @ 40°C / 104°F ambient, 243 W max
Output Voltage 66 series: 6 to 27 Vdc; 70 series: 12 to 47 Vdc
Efficiency 87% with 100% load @ 115 Vac input
System Power Cycle Delay 2 second typical time required for stabilization of all outputs
Output Current Tolerance +/-5 % of nominal
Output Over voltage, over current, short circuit protection
Over Temperature Power supply will shut down when external ambient temperature
exceeds 43°C/ 109.4°F or case temperature reaches 85°C/ 185°F
nominal.
Output Interconnection Hiccup mode with automatic recovery upon removal of short. Only
applies to +ve to -ve interconnections.
Agency Approvals UL 8750 Class 2 outputs
Conducted and Radiated Emissions ICES-003; FCC Title 47, Part 15, Class A (for commercial use only)
EMC EN61547- general lighting
Location Rating Dry
Operating Ambient Temperature -20°C to 40°C / -4°F to 104°F
Cold Start Temperature -20°C / -4°F
Storage Ambient Temperature -40°C to 80°C / -40°F to 176°F
Relative Humidity 5% to 95% noncondensing
Mean Time Between Failure
(MIL HDBK-217F); (12 channel) >60,000 hours @ 40°C / 104°F; >97,000 hours @ 25°C / 77°F
Control Method DMX512-A
DMX Receiver Isolation Isolated from earth ground
Start Codes Will only respond to NULL START code
Loss of DMX Input Signal Outputs will go to 100% light intensity in less than 1 second.
LSPS09 / Trinity PC DMX
