LumaStream 410 Downlight - Manual

Product Description
This fully dimmable low-voltage LED fixture is rated
for insulation contact (IC) as well as airtight and damp
locations. This Class 2 solution contains no electronics
in the fixture. The dimming control, power conversion
and constant current drivers for multiple fixtures
are housed in a remote DC, Class 2 intelligent power
supply which can be located up to 200 ft. away from
the fixtures.
Ideal applications: hospitality, retail, architectural
lighting.
Performance Summary
Light Output 542 - 825 lumens
Drive Current 700 mA, 1000 mA
CRI 80 standard, 90 optional
CCT 2700K, 3000K, 3500K, 4000K
Lifetime 50,000+ hours
Warranty 5 year limited warranty
Dimming Dimmable to 0.2%
410 Downlight
4” Eyeball LED
Adjustable through 30° by 360°
lense allows for multiple lighting
applications.
Schedule ID
Part Number
Notes
Base Beam CCT Lens Housing Baffle Trim
410 N Narrow
(24)
W Wide
(50)
27 2,700K
(opt)
30 3,000K
(std)
35 3,500K
(opt)
40 4,000K
(std)
C Clear
S Soft diffuse
(6%)
F Full diffuse
FL
Flat
RN
Round
RC
remodel
construction
NC
new
construction
B Black
C Clear
(brushed aluminum)
W White
W White
C Clear
(brushed aluminum)
W White
Ordering Information Example: 410-N30S-FLNC-CW
410 - - -
