LumaStream Pelican- Path Light LED User Manual
Pelican, Path light led

Product Description
This fully dimmable low-voltage LED uplight or
downlight mounts either on a stake or canopy mount.
Fixture head has 360° adjustability. It is available in
two LED array options with three (R3) or four (R4)
white diodes. The fixture contains no electronics. All
dimming control, power conversion and constant
current drivers are housed in a remote DC, Class 2
intelligent power supply which can be located up to
200 ft. away from fixtures.
Ideal applications: architectural, hardscape, and
landscape
Performance Summary
Pelican
Path Light LED
Fully adjustable path light
ideal for walkways, plazas or
pedestrian areas.
Light Output
R3: 431- 553 lumens
R4: 581- 745 lumens
Drive Current
500 mA, 700 mA
CRI
82 standard
CCT
2700K, 3000K, 4000K
Lifetime
50,000+ hours
Warranty
5 year limited warranty
Dimming
Dimming to 0.2%
Schedule ID
Part Number
Notes
© 2014 LumaStream
www.lumastream.com
+1 (727) 827-2805
Base
Beam
CCT
Lens
Arm
Stem
Finish
Mount
R3PL
R4PL
0 None
N Narrow
(10)
M Medium
(25)
W Wide
(40)
27 2,700K
30 3,000K
40 4,000K
C Clear
S Soft diffuse
(6%)
F Full diffuse
02 2” Arm
04 4” Arm
06 6” Stem
12 12” Stem
18 18” Stem
24 24” Stem
C Clear
(brushed aluminum)
B Black
0 None
C Canopy
S Stake
Ordering Information
Example: R3PL-N30S-0406-CS
RXPL -
-
-
