LumaStream 330 Honey Glass Pendant - Manual

For more information, please contact:
+1 (727) 827-2805
[email protected]
LumaStream, Inc. reserves the right to make changes without further notice to any products herein to improve reliability, function, or design.
LumaStream does not assume any liability arising out of the application or use of any product described herein; neither does it convey any
license under its patent rights, nor the rights of others.
LS0051 / 330 Pendant
Product Description
This fully dimmable low-voltage LED fixture is a
custom made glass pendant with a honey coloring
and swirl design. This Class 2 solution contains no
electronics in the fixture. The dimming control, power
conversion and constant current drivers for multiple
fixtures are housed in a remote DC, Class 2 intelligent
power supply which can be located up to 200 ft.
away from the fixtures.
Ideal applications: hospitality, retail, and architectural
lighting.
Performance Summary
Light Output 440-596 lumens
Drive Current 500 mA, 700 mA
CRI 80 standard
CCT 2700K, 3000K, 4000K
Lifetime 50,000+ hours
Warranty 5 year limited warranty
Dimming Dimmable to 0.2%
330 Pendant
Honey Glass Pendant LED
Custom made cylindrical glass
pendant with honey swirl
design.
Schedule ID
Part Number
Notes
Base Beam CCT Lens Canopy Wire Color
330 WF Wide Flood 27 2,700K
30 3,000K
40 4,000K
S Soft diffuse 02 2” Canopy
05 5” Canopy 05 5’ Wire
10 10’ Wire
15 15’ Wire
C Clear
(brushed aluminum)
Ordering Information Example: 330-W30S-0260-C
330 - - -
© 2014 LumaStream www.lumastream.com +1 (727) 827-2805
TUV Pending
