LumaStream Weedon- Strap Mount LED - Manual

Product Description
This fully dimmable low-voltage LED uplight or
downlight comes standard with a 5’ dark green
canvas strap and 360° adjustable fixture head and
60° swivel. It is available in two LED array options
with three (R3) or four (R4) white diodes. The fixture
contains no electronics. All dimming control, power
conversion and constant current drivers are housed in
a remote DC, Class 2 intelligent power supply which
can be located up to 200 ft. away from fixtures.
Ideal applications: architectural, hardscape, and
landscape
Performance Summary
Weedon
Strap Mount LED
Adjustable uplight or downlight
with strap mount ideally suited
for expandable attachment.
Light Output R3: 431- 553 lumens
R4: 581- 745 lumens
Drive Current 500 mA, 700 mA
CRI 82 standard
CCT 2700K, 3000K, 4000K
Lifetime 50,000+ hours
Warranty 5 year limited warranty
Dimming Dimming to 0.2%
Schedule ID
Part Number
Notes
© 2014 LumaStream www.lumastream.com +1 (727) 827-2805
Base Beam CCT Lens Swivel Arm Finish
R3MB
R4MB 0 None
N Narrow
(10)
M Medium
(25)
W Wide
(40)
27 2,700K
(opt)
30 3,000K
(std)
40 4,000K
(std)
C Clear
S Soft diffuse
(6%)
F Full diffuse
60 60° Swivel
90 90° Swivel
00 No Arm
02 2” Arm
04 4” Arm
C Clear
(brushed aluminum)
B Black
Ordering Information Example: R3MB-N30S-0460-C
RXMB - - -
