401 Downlight Specifications
Drive Current
CCT
Lumens
Voltage
Watts
Lumens/Watt
CRI
700 mA
3000K
555
11.2
7.8
77
80>
1000 mA
3000K
742
11.4
11.4
66
80>
700 mA
4000K
617
11.2
7.8
79
80>
1000 mA
4000K
825
11.4
11.4
72
80>
Light Output
Dimensions (H x W x D)
New construction: 8.00”H x 8.00”W x 5.16”D
Remodel: 6.00”H x 11.31”W x 5.16”D
Weight
0.80 lbs.
Housing, Finish
Galvanized steel housing
Optics
Polycarbonate
Lenses
Clear or Soft Diffuse Acrylic
Operating Temperature
-4°F to 104°F/ -20°C to 40°C
Mounting Options
Positioned between joists spaced at 12”, 16” or 24” O.C.
Can be mounted to any standard ceiling grid
Construction & Materials
TUV Certified to UL 1598
Yes
IC Rated
Yes
Suitable for Damp Locations
Yes
RoHS Compliant
Yes
Exceeds California Title 24
Yes
LM79 Tested
Yes
Certifications & Qualifications
Mechanical Specifications
© 2014 LumaStream
www.lumastream.com
+1 (727) 827-2805
Remodel
New construction
