Page 28

Programming

F232157

NOTE: Temperature display applies ONLY if

machine is configured for “HEAt” in SETUP

Mode. Machine must be equipped with electric or

steam heat and a temperature sensor. If configured

for “noHt” (no heat capability) in SETUP Mode,

temperature display does not appear in the

segment. After temperature setting, control will

skip to “drAI”/“nodr” or Spin Time, depending on

version. If “HEAt”/ “noHt” does not appear in

SETUP Mode, no heating is possible.

35. If display shows “drAI”/“nodr” during segment

programming, a drain step option will appear at

the end of the segment.

36. Select “drAI” for a drain step followed by an

optional spin. Select “nodr” for no drain step.

NOTE: The machine will proceed directly to the

next segment if “nodr”.

37. Change the selection by pressing the (

∧) or (∨)

keypad or the START (Enter) keypad to continue.

38. If “drAI” is selected (or if your model does not

provide the option of selecting “drAI”/“nodr”),

the display will show “SPIn” one second, “tI

E”

one second, and then the time for spin: “00” (no

spin) for 30-240 seconds IF you are in Rinse 1, 2,

or 3. If you are in Rinse 4, the time for spin will

show 0 or 1-10 minutes.

39. Change the selection by pressing the (

∧) or (∨)

keypad, or the START (Enter) keypad to

continue.

IMPORTANT: The spin time in Rinse 4 is

programmed in minutes (0-10 minutes, in

one-minute increments), while other spins are in

seconds to allow for shorter times (such as

45 seconds). (Rinse 4 segment should usually be

used as the final rinse, even where there may be

fewer than four rinses. Program zero time for

preceding rinses you wish to exclude.)

40. Display shows “0000” if control cannot read

temperature or a temperature if control is capable

of a temperature reading.

41. Exit PROGRAM Mode by moving the Program/

Run switch back to the right as seen from the

front of the machine.

NOTE: The SPIN indicator LED will automatically

light during the wash cycle when the last spin

programmed in a cycle is operating (regardless of

which segment).

Abnormal Conditions

Door Will Not Lock

If the door handle has not been properly positioned to

allow locking the door, the control will sense this and

retract the door lock solenoid. The display will show

“----” for about 5 seconds, then will flash “SHUt”/

“dOOr” for about 5 seconds while sounding the

buzzer, prompting the user to close the door properly.

The DOOR indicator LED then lights. The machine

user should properly shut the door, then press START

(Enter) again. If the door is still not locking correctly,

the process above will repeat up to five times. After

this, the display flashes “CAnt”/“LOC” (cannot lock

door). The user can cause this to start over (five more

attempts) by pressing START (Enter) keypad twice. If

this continues, it indicates a problem, and a qualified

service technician should be consulted.

Door Open During Operation

If the control senses either a momentary or sustained

open door while the machine is operating in a wash

cycle, the control immediately attempts to halt rotation

of the cylinder. All outputs not required to effect rapid

halting of the cylinder rotation de-energize

immediately. The message “dOOr” then displays as

long as the condition persists. Regardless of the

duration of the open door condition, once it is

recognized by the control, the control aborts the cycle

and goes to the stop routine even if the door is closed.

Excessive Fill Time

Fill times exceeding 10 minutes cause the cycle to

abort. Display flashes “StOP”/“FILL” and sounds the

buzzer for 10 seconds prior to entering the stop routine

(display shows “01” minutes remaining while in the

stop routine). The Fill Error Count will increase by

one. Refer to Cycle and Error Count section.

Out-of-Balance

If the machine goes out of balance, the machine will

attempt to balance the load. After three attempts, the

display will light the leftmost digit and a lower spin

will be used.

Operating the machine with severe out-of-

balance loads could result in personal

injury and serious equipment damage.

W728

WARNING
