Programming
25 F232157
NOTE: If temperature is not reached after
40 minutes, control resumes cycle.
After cycle resumes, control will attempt to maintain
programmed temperature if it senses water in the
machine.
NOTE: Temperature display applies ONLY if
machine is configured for “HEAt” in SETUP
Mode. Machine must be equipped with electric or
steam heat and a temperature sensor. If configured
for “noHt” (no heat capability) in SETUP Mode,
temperature display does not appear in the
segment. After temperature setting, control will
skip to “drAI”/“nodr” or Spin Time, depending on
version.
19. If display shows “drAI”/“nodr” during segment
programming, a drain step option will appear at
the end of the segment.
20. Select “drAI” for a drain step followed by an
optional spin. Select “nodr” for no drain step.
NOTE: The machine will proceed directly to the
next segment if “nodr”.
21. Change the selection by pressing the ( ∧) or (∨)
keypad, or the START (Enter) keypad to
continue.
22. If “drAI” is selected (or if your model does not
provide the option of selecting “drAI”/“nodr”),
the display will show “SPIn” one second, “tI
n
E”
one second, and then the time for spin: “00” (no
spin) or 30-240 seconds.
23. Change the selection by pressing the ( ∧) or (∨)
keypad or the START (Enter) keypad to continue.
Rinse 1 – Rinse 4
NOTE: Programming a time other than “00” for
this step will make the RINSE indicator LED light
while this step is running, but not in PROGRAM
Mode.
24. The main display shows “rIN1” indicating you
are in the Rinse segment (number will represent
Rinse cycle selected 1-4).
25. Press START (Enter) keypad. Display shows the
time for agitation during the step: “00” (skips
segment) or 2-15 minutes. This is the time after
the fill and before the drain and does not include
spin time.
26. Press the ( ∧) or (∨) keypad to alter the selection,
or the START (Enter) keypad to continue.
27. Display shows “CFIL”, “HFIL”, “bFIL” or
“EFIL” for Cold, Hot, Both (warm) or Extra fill.
28. Press the ( ∧) or (∨) keypad to alter the selection,
or the START (Enter) keypad to continue.
NOTE: Extra fill (“EFIL”) is possible only if
configured for “EFIL” in SETUP Mode. If
configured, a third valve can be controlled.
29. Display shows “LO”, “
n
Ed”, or “HI” for Low,
Medium, or High water level, respectively.
30. Press the ( ∧) or (∨) keypad to alter the selection,
or the START (enter) keypad to continue.
31. Display shows “SUP0”, “SUP1”, “SUP2”,
“SUP3”, or “SUP6” (or “S 12” depending on
version of control). Refer to Table 2 for operation
of each supply selection.
32. Press the ( ∧) or (∨) keypad to alter the selection,
or the START (Enter) keypad to continue.
NOTE: If programmed for “SUP2”, the ADD
BLEACH indicator LED light turns on and is set
up for “bEEP” the buzzer sounds for the first eight
seconds Supply 2 is on.
Heated Models Only
33. Display shows temperature in degrees F or C.
Display will show degrees F if configured for
“FAr” in SETUP Mode, or degrees C if
configured for “CEL” in SETUP Mode. Range is
80°F to 205°F, or 00F (no heat for segment), or
27°C to 95°C, or 00C (no heat for segment).
34. Press the ( ∧) keypad to increase, or (∨) keypad
to decrease temperature. Temperature changes in
one-degree increments.
The control will energize heat and pause cycle timing
for up to 40 minutes until the programmed temperature
is first reached.
NOTE: If temperature not reached after
40 minutes, control resumes cycle.
After cycle resumes, control will attempt to maintain
programmed temperature if it senses water in the
machine.
To prevent personal injury, avoid contact
with inlet water temperatures higher than
125° Fahrenheit (51° Celsius) and hot
surfaces.
W748
WARNING
