Kasco Marine J Series - Manual (Page 6)

Attach 3 cable ties
to top ring equally spaced
2 inch overlap
Flip mesh and screen assembly over and use
remaining cable ties to secure mesh to small bottom
diameter of the stainless steel ring.
Attach 2 cable ties
to bottom ring equally spaced
Clip off excess cable tie material once mesh is secured
into place.
Position the Bottom Screen (Part #B6) over the float
Overlap vertical edges
1 inch overlap
Attach 3 cable ties
Place mesh cone on flat surface with small diameter at
bottom. Insert existing stainless steel screen centered
inside mesh cone with approximately 2 inches of mesh
overlap to the top ring of the screen. Attach mesh
to the top ring of the screen in (3) equally spaced
locations using cable ties.
