Fig. 4. A direct distance
measurement of 5 feet,
1 and 15/16 inches
In direct distance measurement mode,
you can display up to four consecutive
measurements in the order in which they
were made. Fig. 5 is a screen shot which
shows the values of four direct distance
measurements made in top-to-bottom order.
Fig. 5. Four direct distance
measurements made in
order from top to bottom
Continuous Distance Measurement
(Distance Tracking)
This operating mode is ideal for
transferring measurements from
construction plans or blueprints. In practice,
you walk the meter back from a wall a specified distance while
the meter tracks its own position by measuring the distance to
the wall twice per second. As you make these dynamic
measurements and you close in on the specified distance, the
meter takes note of the closest and farthest you have been from
the wall and displays these minimum and maximum distances
along with the final distance.
Before entering continuous distance measurement mode, be
sure to temporarily change the measurement reference from the
rear of the meter to the front (see p. 12). Next, hold the meter
horizontally with its top against the wall shown on a plan. Then,
after making sure that the laser is on, press the
button and
back away from the wall while continuing to point the laser at
15
15 /
16 5’01”
➤
21 08
13 /
16
3 /
4
1 /
8 113 04
53 03
3 03
7 /
8
➤
