INTRODUCTION
Thank you for purchasing General Tools & Instruments’ E•Z Pro ™ Deluxe Doweling Jig
Kit. The E•Z Pro Deluxe Doweling Jig Kit is a simple and straight forward device that’s
easy to set-up and simple to use. It is intended to assist you in centering and aligning
dowels on stock that is nominally 5/8", 3/4" or 1" thick. When the stock is greater than
1" thick, registration may be alternated between the top and bottom surfaces to achieve
balanced doweling. (See Figure A on page 5)
ANATOMY OF THE E•Z PRO DELUXE DOWELING JIG
3
BACK AND TOP BUSHING LOCATIONS
BUSHING LOCATIONS (IN PAIRS) USED FOR:
BACK INSIDE
CLAMP
NOMINAL
1" THICK
STOCK
NOMINAL
3/4" THICK
STOCK
NOMINAL
5/8" THICK
STOCK
“V” POINTS
FOR EDGE AND
SURFACE
ALIGNMENT
