GENERAL PUMP
A member of the Interpump Group
SM SERIES
Remove the ring gear support ring (1, fig. 16).
Remove the connecting rod caps with the lower semi-bearings, taking special care of the disassembly
sequence during disassembly.
The connecting rod caps and their relative half supports must be reassembled in exactly the
same order and coupling with which they were disassembled.
To avoid possible errors, caps and half supports have been numbered on one side (1, fig. 18).
Page 8
Unscrew the connecting rod screws (1, fig. 17).
Ref 300894 Rev.A
06-12
