Finish Thompson DB 11/15 Series - Manual (Page 13)

13
1. Select Base Model (Example: DB11P) *
2. If Standard Components aren’t suitable, enter symbol(s) of alternative components in any order.
Base Model - - - - -
DB11P - E - U - 14
(Example: DB11P-E-U-14 is a DB11P with EPDM o-ring, unions and 145TC motor adapter.)
3. Alternative Components - select from below
PART NUMBER EXPLANATION
*The model number is on the serial
number label located on the motor
adapter. The model number contains
a base model that features certain
standard components. Compare the
model number on the pump to the
chart below to determine if the pump
contains any alternate components.
Model numbers containing “P” have
primary components molded from
polypropylene. Model numbers
containing “V” have primary compo-
nents molded from PVDF.
Base Model Numbers: DB11P, DB11V,
DB15P, DB15V
