Fire Fighting Enterprises FIRERAY 3000 - Manual (Page 15)

15
18. Technical Specifications
Parameter Value
Operating Distance between Transmitter and Receiver 5 - 120m
Operating Voltage Range 12 to 36V DC +/- 10%
Transmitter Current 8mA
Quiescent Current (Controller with 1 or 2 Receivers) 14mA
Alarm Current (Controller with 1 or 2 Receivers) 14mA
Fault Current (Controller with 1 or 2 Receivers) 14mA
Power Down Reset Time >20 seconds
Fire and Fault Relay Contacts VFCO 2A@ 30 Volts DC, resistive
Maximum Cable Length (Controller to Receiver) 100m
Cable Gauge
24 - 14 AWG
0.5 - 1.6mm
Operating Temperature
-10°C to +55°C (non-condensing)- EN
-20°C to +55°C (non-condensing)- UL
Storage Temperature -40°C to +85°C (non-condensing)
Receiver Tolerance to Beam Misalignment at 25% sensitivity ± 2.5°
Transmitter Tolerance to Beam Misalignment at 25% sensitivity ± 0.7°
Fire Threshold Range
0.45 - 3.98 dB
10 - 60%
Delays to Fire and Fault 2-30s, individually selectable
Optical Wavelength 850nm
Rapid Obscuration Fault Threshold 85%
LED Indications - Control Unit
Red = Fire (one for each Receiver)
Amber = Fault (one for each Receiver)
Green = System OK
LED Indications - Receiver
Red = Fire. Green and Amber indication LEDs for
single-person alignment
IP Rating IP54
Relative Humidity (Max.) 93%, (non-condensing)
CPD Reference 0786-CPD-21162
UL File S3417 (volume 6)
Housing Construction (Controller/Transmitter/Receiver) UL94 V0 PC
Dimensions
Width,
mm (in)
Height,
mm (in)
Depth,
mm (in)
Weight,
kg (lb)
Control Unit
202.7 (7.98) 124 (4.9) 71.5 (2.82) 0.606 (1.34)
Transmitter & Receiver
77.6 (3.05) 77.6 (3.05) 160 (6.3) 0.207 (0.46)
inc. brackets
