INTERVAL DATA RECORDER (IDR)
62-0394-03 38
Appendix I - Hard Wired System Configuration
Diagrams (Continued)
IDR-16, USING OTHER UTILITY-TYPE METERS
(GAS, WATER, ETC.)
UP TO 16 METERS
UP TO 16 METERS
CHANNEL 2
~~
~~
CHANNEL 1
CHANNEL 3
AC ADAPTER
UP TO 16 METERS
UP TO 16 METERS
IDR-16, USING E-MON D-MON ® METERS
UP TO 16 METERS
UP TO 16 METERS
CHANNEL 2
~~
CHANNEL 1
CHANNEL 3
UP TO 26
IDR-16S
NOTES: METERS 1-16 MUST BE INSTALLED WITHIN 500 FEET OF IDR.
METERS 1-16 USE 6-CONDUCTOR CABLE.
AC ADAPTER
RS-232
KEY*
6 FOOT CABLE
PROVIDED BY
E-MON (15
FEET MAX)
RS-232
SERIAL PORT
COM1-COM4
UP TO 16 METERS
UP TO 16 METERS
AC ADAPTER
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR
M33742
PC
UP TO 4000
FEET TOTAL
UP TO 4000
FEET TOTAL
UP TO 26
IDR-16S
PC
6 FOOT CABLE
PROVIDED BY
E-MON (15
FEET MAX)
RS-232
SERIAL PORT
COM1-COM4
RS-232
KEY*
UP TO 4000
FEET TOTAL
UP TO 4000
FEET TOTAL
AC ADAPTER
AC ADAPTER
UP TO 26
IDR-16S
UP TO 26
IDR-16S
AC ADAPTER
AC ADAPTER
NOTES: METERS MUST BE INSTALLED WITHIN 500 FEET OF IDR.
METER CONNECTED WITH A PAIR OF #22-#14 AWG CONDUCTORS.
AC ADAPTER
AC ADAPTER
AC ADAPTER
~~
