8.0 IDR PROTOCOL DEFINITIONS
Modbus Customer Point Map: IDR8 and IDR16
Integer
Address
Float
Address Registers Description
Integer
Units Float Units IDR
40001
1
41001
1 2 Usage Channel 1 Pulse Pulse
* Pulse Value
R/W
40003
1
41003
1 2 Usage Channel 2 Pulse Pulse
* Pulse Value
R/W
40005
1
41005
1 2 Usage Channel 3 Pulse Pulse
* Pulse Value
R/W
40007
1
41007
1 2 Usage Channel 4 Pulse Pulse
* Pulse Value
R/W
40009
1
41009
1 2 Usage Channel 5 Pulse Pulse
* Pulse Value
R/W
40011
1
41011
1 2 Usage Channel 6 Pulse Pulse
* Pulse Value
R/W
40013
1
41013
1 2 Usage Channel 7 Pulse Pulse
* Pulse Value
R/W
40015
1
41015
1 2 Usage Channel 8 Pulse Pulse
* Pulse Value
R/W
40017
1
41017
1 2 Usage Channel 9 Pulse Pulse
* Pulse Value
R/W
40019
1
41019
1 2 Usage Channel 10 Pulse Pulse
* Pulse Value
R/W
40021
1
41021
1 2 Usage Channel 11 Pulse Pulse
* Pulse Value
R/W
40023
1
41023
1 2 Usage Channel 12 Pulse Pulse
* Pulse Value
R/W
40025
1
41025
1 2 Usage Channel 13 Pulse Pulse
* Pulse Value
R/W
40027
1
41027
1 2 Usage Channel 14 Pulse Pulse
* Pulse Value
R/W
40029
1
41029
1 2 Usage Channel 15 Pulse Pulse
* Pulse Value
R/W
40031
1
41031
1 2 Usage Channel 16 Pulse Pulse
* Pulse Value
R/W
40065 41065 2 Demand Channel
1
Demand Demand
* Pulse Value
R
40067 41067 2 Demand Channel
2
Demand Demand
* Pulse Value
R
