INTERVAL DATA RECORDER (IDR)
62-0394-03 20
46049
5 8 Custom EZ7 ID, Modbus ID, Serial Number R/W
46057 8 Custom Recorder Info., Demand Interval R/W
46513 8 Custom Flags L1: Power Failure, Battery R
46521 8 Custom Flags L2: Power Failure Date R
1. To set the interval data day block, set multiple points at 44001 for 6 points with data
set to 0C0I 0000 MMDD YYYY 0000 0000. 0C = Channel, 0I = Interval (0F = 15
minute intervals, 05 = 5 minute intervals)
2. Each register represents a 15 or 5 minute pulse value based on the interval day
block. 96 registers max with 15 minute intervals. 288 registers max with 5 minute
intervals. The first interval data register 44007 represents the pulse count for the first
15 or 5 minute interval beginning at midnight.
3. The interval data headers represent days with available interval data. Each day
represents 2 registers. Format: MMDD YYYY.
4. To set the date and time, set multiple points at 46025 for 4 points with data set to
HHMM SSDW MMDD YYYY (DW=day of week)
5. To change the Modbus ID, set single point at 46050 with data set to new Modbus ID
(e.g. 1 to 247). Jumper J6 must be closed.
With an IDR16 each channel 1 through 16 represents the IDR16 meter jack inputs 1
through 16.
With an IDR8 each channel 1 through 8 represents the IDR8 meter jack inputs 1
through 8.
BACnet Object Descriptors Customer: IDR8 and IDR16
Instance
ID BACnet Object
Description
Units
BACnet
Property IDR
1
1 Analog Input Usage Channel 1 Pulse * Pulse Value Present
Value
R
2
1 Analog Input Usage Channel 2 Pulse * Pulse Value Present
Value
R
3
1 Analog Input Usage Channel 3 Pulse * Pulse Value Present
Value
R
4
1 Analog Input Usage Channel 4 Pulse * Pulse Value Present
Value
R
5
1 Analog Input Usage Channel 5 Pulse * Pulse Value Present
Value
R
6
1 Analog Input Usage Channel 6 Pulse * Pulse Value Present
Value
R
7
1 Analog Input Usage Channel 7 Pulse * Pulse Value Present
Value
R
