E-Mon EIDR-16J*RJ - Manual (Page 19)

INTERVAL DATA RECORDER (IDR)
19 62-0394-03
40069 41069 2 Demand Channel
3
Demand Demand
* Pulse Value
R
40071 41071 2 Demand Channel
4
Demand Demand
* Pulse Value
R
40073 41073 2 Demand Channel
5
Demand Demand
* Pulse Value
R
40075 41075 2 Demand Channel
6
Demand Demand
* Pulse Value
R
40077 41077 2 Demand Channel
7
Demand Demand
* Pulse Value
R
40079 41079 2 Demand Channel
8
Demand Demand
* Pulse Value
R
40081 41081 2 Demand Channel
9
Demand Demand
* Pulse Value
R
40083 41083 2 Demand Channel
10
Demand Demand
* Pulse Value
R
40085 41085 2 Demand Channel
11
Demand Demand
* Pulse Value
R
40087 41087 2 Demand Channel
12
Demand Demand
* Pulse Value
R
40089 41089 2 Demand Channel
13
Demand Demand
* Pulse Value
R
40091 41091 2 Demand Channel
14
Demand Demand
* Pulse Value
R
40093 41093 2 Demand Channel
15
Demand Demand
* Pulse Value
R
40095 41095 2 Demand Channel
16
Demand Demand
* Pulse Value
R
Modbus Customer Point Map: IDR8 and IDR16
Address Registers Format Description IDR
44001
1 6 Custom Interval Day Block R/W
44007
2 1 per interval Integer Interval Data R
45501
3 2 per day Custom Interval Data Headers R
46025
4 8 Custom RTC Date/Time R/W
Modbus Customer Point Map: IDR8 and IDR16
Integer
Address
Float
Address Registers Description
Integer
Units Float Units IDR
